Ion 5090 Astral GPU Water-block Acrylic

In stock

Order processing time 1-2 days.

  • Full-cover GPU water-block for RTX 5090 Astral
  • Electroless nickel-plated copper cold plate cools GPU, VRMs and memory
  • Triple-layer jet plate and fine fin array for maximum heat transfer
  • High-flow design for even cooling across all components
  • Precision CNC-machined construction with high-quality materials
  • Available in Acrylic, Nickel, PCB Cover and Carbon Fiber versions
  • Multiple color and finish options available for the Acrylic version

Use distilled water at your own risk, coolant is recommended.

Manuals

US$349.00

Select Accent Cover Color/Finish Options
None Satin Black Gloss Black Gloss White Carbon Mirror Silver Mirror Gold Mirror Carbon Fiber Satin Black

The water-block will remain transparent, the option is for the covers.
(Satin Black shown in product images, if you select none you will receive Satin Black.)

  • 1x Ion 5090 Astral GPU Water-block Acrylic
    US$349.00

Subtotal excludes shipping & tax

Free shipping on orders over US$2,000
  • Made In Australia
  • Lifetime warranty & expert support
Fully secured - SSL CheckoutAccepted payment methods
EAN: 9362188001721 SKU: SC-GPUWB-5090-AST-AC Category:

Description

Read More +Read Less − full description

The Ion 5090 Astral GPU Water-block has an electroless nickel plated copper cold plate which actively cools not only the GPU but also the VRMs and Memory. It has a jet plate and fin array with a triple layer design for maximum flow, and for even flow over the components. The fin stack is fine for maximum heat transfer. High-quality materials and precision CNC machining. There are four types available Acrylic, Nickel, PCB Cover and Carbon Fiber. The difference between these is the material the cover is made from. The acrylic version also has various color and finish options available.



Specifications

Ion Astral GPU Water-block Versions:
The Ion Astral GPU Water-block comes in 4 versions. The Acrylic version has an acrylic top cover with an accent cover which can be black satin, black gloss, gold, silver, dark chrome, gloss white and carbon fiber. It also has integrated ARGB lights.
The Nickel version has a solid Nickel-plated Brass top and it has no ARGB.
The PCB Cover version has a PCB cover with integrated ARGB lights and is a more compact and subtle option.
The Carbon Fiber version has a Carbon Fiber top and is also a more compact and subtle version, it has no ARGB.

Specifications:
Ion Astral 5090 GPU Water-block.
Ion Astral 5090 GPU Water-block Back Plate: CNC Machined Anodized Black Aluminum (does not come into contact with coolant).
Thermal Pads.
Fasteners.
Ion 5090 Astral GPU Water-block Acrylic.
CNC Machined Nickel-Plated Copper Cold Plate.
CNC Machined Acrylic Covers.
CNC Machined Aluminum Back Plate.
ARGB PCB.
Laser cut Aesthetic Acrylic Cover or Carbon Fiber (select color and finish option above).
Dimensions: L: 300mm x W: 120mm x H: 30mm.
Weight: 3.5kg.
Packaged Dimensions: L: 300mm x W: 120mm x H: 30mm.
Packaged Weight: 4kg.

Installation:
Replaces the stock cooler on the Asus Astral 5090, see installation manual.
