Home / Shop / Distribution Plates / Lian Li / Lian Li V3000+ Single Loop Distribution Plate Set

Lian Li V3000+ Single Loop Distribution Plate Set

In stock

Order processing time 1-2 days.

  • Two-piece single-loop distribution plate set for the Lian Li V3000+
  • Designed for the standard motherboard orientation
  • Includes Dual D5 Reservoir Distribution Plate and rear-mounted Distribution Plate
  • Dual D5 pumps in series for single-loop operation
  • Installs using existing case mounting holes with no modifications
  • Maximum reservoir volume for easier filling and air removal
  • CNC-machined clear cast acrylic with durable gasket seals
  • Integrated ARGB LED strips with customizable covers
  • Includes Back Plates to conceal the rear of the distribution plates
  • Hand assembled with stainless steel fasteners
  • Compatible with both Lian Li V3000+ Mid Distribution Plate versions
  • Not compatible with the rotated motherboard orientation Mid Distribution Plates

Manuals

US$129.00 US$399.00Price range: US$129.00 through US$399.00

Select Acrylic Cover and Back Plate Color/Finish Options
None Satin Black Gloss Black Gloss White Carbon Mirror +US$31.92 Silver Mirror +US$31.92 Gold Mirror +US$31.92 Satin Black

The distribution plate will remain transparent, this colour option is for the covers and back plates.
(Satin Black shown in product images, if you select none you will receive Satin Black.)

Select Acrylic Cover and Back Plate Color/Finish Options
None Satin Black Gloss Black Gloss White Carbon Mirror +US$22.32 Silver Mirror +US$22.32 Gold Mirror +US$22.32 Satin Black

The distribution plate will remain transparent, this colour option is for the covers and back plates.
(Satin Black shown in product images, if you select none you will receive Satin Black.)

Select Acrylic Cover and Back Plate Color/Finish Options
None Satin Black Gloss Black Gloss White Carbon Mirror +US$10.32 Silver Mirror +US$10.32 Gold Mirror +US$10.32 Satin Black

The distribution plate will remain transparent, this colour option is for the covers and back plates.
(Satin Black shown in product images, if you select none you will receive Satin Black.)

Select D5 Retention Ring Colour x2 (included)
None Black Silver Black

Protium Retention Ring
Protium 3.0 uses a retention ring design instead of threaded caps. This allows for 360-degree rotation of the reservoir caps, and it is far more durable than caps which thread onto the inside of the reservoir tube. They are built from CNC Machined Anodized Aluminum and do not contact the fluid. They are compatible with Protium 3.0 ARGB 150 D5 Reservoir Combos, Protium 3.0 Reservoir 200mm and backwards compatible with Protium 1.0 and 2.0.

Optional Add-Ons

Enhance your purchase with these recommended extras

Distribution Plates

V3000+ Mid Distribution Plate (optional)
None V3000+ Mid Distribution Plate +US$249.00 V3000+ Mid Distribution Plate Vertical GPU +US$229.00

Lian Li V3000 Mid Distribution Plate
Mid Distribution Plate options for Horizontally and Vertically Mounted GPUs.

Water Cooling

D5 Pump Cover Options x2 (optional) USD $78
None Black +US$78.00 Silver +US$78.00

Protium D5 Pump Cover
The SC Protium 3.0 ARGB Pump Cover is built from thick CNC machined anodized aluminum and comes in Black and Silver. It has an integrated ARGB/DRGB PCB which also acts as the rear cover for the D5 Pump. The Pump Cover glows from the back with LEDs around the perimeter of the rear cover. The cover has a 3-piece design for compatibility with all D5 pumps including the Aquacomputer D5 Next.

D5 Pump x2 (optional) USD $208
None Yes +US$208.00

Protium D5 Pump
The Protium 3.0 D5 Pump is compatible with all products which fit a D5 pump. The D5 pump has legendary reliability and performance. We have used it in almost every system we have ever built. The pump moves 1500LPH of fluid and has a head pressure of 3.7M. It has a Molex connector for power and a PWM connector to control the RPM.

Stop Fitting x2 (optional) USD $8
None Yes +US$8.00

Stop Fitting
Singularity Computers Fittings have been designed based on our extensive experience building water-cooled systems. They are built from CNC machined brass and powder coated in matte black and have silicone O-Rings. Our goal was to create something which is aesthetically subtle, and easy and effective to use. The fittings are compact enough to fit into the tight places fittings are needed, while allowing for a wide variety of different configurations.

Finish & personalisation

Enter text you would like laser etched onto the coloured distribution plate cover you have selected.

  • 1x Lian Li V3000+ Single Loop Distribution Plate Set
    US$129.00 US$399.00Price range: US$129.00 through US$399.00

Subtotal excludes shipping & tax

Free shipping over US$2,000 | 30% Off Storewide With Coupon SCA30
  • Made In Australia
  • Lifetime warranty & expert support
Fully secured - SSL CheckoutAccepted payment methods
SKU: N/A Category:

Description

Read More +Read Less − full description

The Lian Li V3000+ Single Loop Distribution Plate Set comes with two distribution plates, a Dual D5 and Reservoir Distribution Plate for installation next to the motherboard and a Distribution Plate for installation on the rear panel. These Distribution Plates are designed for the standard case orientation. The D5 pumps are in series for a single loop configuration. Both Distribution Plates Attach to existing holes on the case, there is no need for modifications. They are built from CNC machined clear cast acrylic and use gaskets instead of O-Rings for increased durability. They are hand assembled with stainless steel fasteners. Designed for maximum reservoir volume to make filling and air removal easier. Each Distribution Plate has an integrated ARGB LED strip with a cover and there are Back Plates included to cover the rear side of the Distribution Plates, select from the different color options below for the covers.

Compatibility: The Single Loop and Dual Loop Distribution Plate Sets can be used with both Mid Distribution Plate versions and are for the standard motherboard orientation. The Rotated Orientation Distribution Plate set is not compatible with the Mid Distribution Plate Sets and is designed for the rotated motherboard orientation.

Youtube video

Youtube video

Specifications

Lian Li V3000+ Single Loop Distribution Plate Set
Specifications:
Lian Li V3000+ Single Loop Distribution Plate Set. The set can be purchased together or they can be purchased separately (select above).
Lian Li V3000+ Dual D5 Reservoir Distribution Plate.
Lian Li V3000+ Dual D5 Reservoir Distribution Plate Back Cover (select color/finish above).
Lian Li V3000+ Rear Distribution Plate.
Lian Li V3000+ Rear Distribution Plate (select color/finish above).
Integrated Reservoir.
Integrated D5 Pump Top x2.
D5 Pump Cover CNC Machined Anodized Aluminum x2 (select color above).
Integrated LED Strip: ARGB 5V with 50cm cable.
Fasteners: Stainless Steel.
D5 O-Rings: Silicone Clear x2.
Gaskets: Silicone Black.
Materials: Cast Acrylic.
Manufacturing Process: CNC Router.
Assembly: Assembled by hand and pressure tested.
Single Loop Distribution Plate Set
Dimensions: L: 500mm x W: 300mm x H: 100mm.
Weight: 8kg.
Packaged Dimensions: L: 550mm x W: 350mm x H: 150mm.
Packaged Weight: 8kg.
Dual D5 Reservoir Distribution Plate
Dimensions: L: 400mm x W: 300mm x H: 40mm.
Weight: 3kg.
Packaged Dimensions: L: 500mm x W: 300mm x H: 50mm.
Packaged Weight: 3kg.
Rear Distribution Plate
Dimensions: L: 300mm x W:120mm x H: 16mm.
Weight: 1kg.
Packaged Dimensions: L: 300mm x W: 200mm x H: 50mm.
Packaged Weight: 1kg.

Installation:
Install into the Lian Li V3000+ next to the motherboard and install the Lian Li V3000+ Rear Distribution Plate on the rear panel above the expansion slots. Align with existing mounting holes on the case and use the included M4 x 12mm Fasteners to attach the Distribution Plates.

Lian Li V3000+ Mid Distribution Plate
Specifications:
There are two different version of this distribution plate available on this page (select above).
Lian Li V3000+ Mid Distribution Plate.
Lian Li V3000+ Mid Distribution Plate Back Cover (select color/finish above).
Lian Li V3000+ Mid Vertical GPU Distribution Plate.
Lian Li V3000+ Mid Vertical GPU Distribution Plate Back Cover (select color/finish above).
Integrated LED Strip: ARGB 5V with 50cm cable.
Fasteners: Stainless Steel.
Gaskets: Silicone Black.
Materials: Cast Acrylic.
Manufacturing Process: CNC Router.
Assembly: Assembled by hand and pressure tested.
Packaged Weight: 3kg.
Packaged Dimensions: H: 500mm x W: 300mm x D: 50mm.

Installation:
Install onto the mid plate of the Lian Li V3000+. Align with existing mounting holes on the case and use the included M4 x 12mm Fasteners to attach the Distribution Plate.
