Phanteks Enthoo Elite Dual Loop Distribution Plate Set

In stock

Order processing time 1-2 days.

  • Dual-loop distribution plate set for the Phanteks Enthoo Elite
  • Includes vertical and horizontal distribution plates
  • Two separate D5 pumps and reservoirs for independent loops
  • Vertical plate mounts to the right of the motherboard
  • Horizontal plate mounts below the motherboard on the mid plate
  • Horizontal plate designed for the GPU loop and lower radiators
  • CNC-machined clear cast acrylic with durable gasket seals
  • Integrated ARGB LED strips with customizable covers
  • Includes Back Plates to conceal the rear of the distribution plates
  • Hand assembled with stainless steel fasteners

Manuals

US$249.00 US$599.00Price range: US$249.00 through US$599.00

Select Acrylic Cover and Back Plate Color/Finish Options
None Satin Black Gloss Black Gloss White Carbon Mirror +US$47.92 Silver Mirror +US$47.92 Gold Mirror +US$47.92 Satin Black

The distribution plate will remain transparent, this colour option is for the covers and back plates.
(Satin Black shown in product images, if you select none you will receive Satin Black.)

Select Acrylic Cover and Back Plate Color/Finish Options
None Satin Black Gloss Black Gloss White Carbon Mirror +US$28.72 Silver Mirror +US$28.72 Gold Mirror +US$28.72 Satin Black

The distribution plate will remain transparent, this colour option is for the covers and back plates.
(Satin Black shown in product images, if you select none you will receive Satin Black.)

Select Acrylic Cover and Back Plate Color/Finish Options
None Satin Black Gloss Black Gloss White Carbon Mirror +US$19.92 Silver Mirror +US$19.92 Gold Mirror +US$19.92 Satin Black

The distribution plate will remain transparent, this colour option is for the covers and back plates.
(Satin Black shown in product images, if you select none you will receive Satin Black.)

Select D5 Retention Ring Colour x2 (included)
None Black Silver Black

 Protium Retention Ring
Protium 3.0 uses a retention ring design instead of threaded caps. This allows for 360-degree rotation of the reservoir caps, and it is far more durable than caps which thread onto the inside of the reservoir tube. They are built from CNC Machined Anodized Aluminum and do not contact the fluid. They are compatible with Protium 3.0 ARGB 150 D5 Reservoir Combos, Protium 3.0 Reservoir 200mm and backwards compatible with Protium 1.0 and 2.0.

Optional Add-Ons

Enhance your purchase with these recommended extras

Water Cooling

D5 Pump Cover Options x2 (optional) USD $78
None Black +US$78.00 Silver +US$78.00

Protium D5 Pump Cover
The SC Protium 3.0 ARGB Pump Cover is built from thick CNC machined anodized aluminum and comes in Black and Silver. It has an integrated ARGB/DRGB PCB which also acts as the rear cover for the D5 Pump. The Pump Cover glows from the back with LEDs around the perimeter of the rear cover. The cover has a 3-piece design for compatibility with all D5 pumps including the Aquacomputer D5 Next.

D5 Pump x2 (optional) USD $208
None Yes +US$208.00

Protium D5 Pump
The Protium 3.0 D5 Pump is compatible with all products which fit a D5 pump. The D5 pump has legendary reliability and performance. We have used it in almost every system we have ever built. The pump moves 1500LPH of fluid and has a head pressure of 3.7M. It has a Molex connector for power and a PWM connector to control the RPM.

Stop Fitting x3 (optional) USD $12
None Yes +US$12.00

Stop Fitting
Singularity Computers Fittings have been designed based on our extensive experience building water-cooled systems. They are built from CNC machined brass and powder coated in matte black and have silicone O-Rings. Our goal was to create something which is aesthetically subtle, and easy and effective to use. The fittings are compact enough to fit into the tight places fittings are needed, while allowing for a wide variety of different configurations.

Finish & personalisation

Enter text you would like laser etched onto the coloured distribution plate cover you have selected.

  • 1x Phanteks Enthoo Elite Dual Loop Distribution Plate Set
    US$249.00 US$599.00Price range: US$249.00 through US$599.00

Subtotal excludes shipping & tax

Free shipping on orders over US$2,000
  • Made In Australia
  • Lifetime warranty & expert support
Fully secured - SSL CheckoutAccepted payment methods
SKU: N/A Category:

Description

Read More +Read Less − full description

Horizontal and Vertical Distribution Plate Set for the Phanteks Enthoo Elite. This is a dual loop distribution plate set with two separate D5 pumps and Reservoirs. The Vertical Distribution Plate mounts to the right of the motherboard and has two integrated reservoirs and D5 pump tops. The Horizontal Distribution Plate mounts below the motherboard on the mid plate and is for the GPU loop and lower radiators. The distribution plates are built from CNC machined clear cast acrylic and uses gaskets instead of O-Rings for increased durability. They are hand assembled with stainless steel fasteners. Each Distribution Plate has an integrated ARGB LED strip with a cover and there are Back Plates included to cover the rear side of the Distribution Plates, select from the different color options below for the covers.

Specifications

Phanteks Enthoo Elite Dual Loop Distribution Plate Set. The set can be purchased together or they can be purchased separately (select above).
Phanteks Enthoo Elite Dual D5 Reservoir Distribution Plate.
Phanteks Enthoo Elite Dual D5 Reservoir Distribution Plate Back Cover (select color/finish above).
Phanteks Enthoo Elite Mid Distribution Plate.
Phanteks Enthoo Elite Mid Distribution Plate (select color/finish above).
Integrated Reservoirs: x2.
Integrated Pump Tops: D5 x2.
D5 Pump Cover CNC Machined Anodized Aluminum x2 (select color above).
Integrated LED Strip: ARGB 5V with 50cm cable x2.
Fasteners: Stainless Steel.
D5 O-Rings: Silicone Clear x2.
Gaskets: Silicone Black.
Materials: Cast Acrylic.
Manufacturing Process: CNC Router.
Assembly: Assembled by hand and pressure tested.
Dimensions & Weight:
Phanteks Elite Dual Loop Distribution Plate Set: L: 550mm x W: 350mm x H: 100mm. 8kg.
Phanteks Elite Dual Loop D5 Reservoir Distribution Plate: L: 400mm x W: 350mm x H: 40mm. 4kg.
Phanteks Elite Mid Distribution Plate: L: 550mm x W: 350mm x H: 16mm. 4kg.
Packaged Dimensions & Weight:

Phanteks Elite Dual Loop Distribution Plate Set: L: 600mm x W: 400mm x H: 100mm. 8kg.
Phanteks Elite Dual Loop D5 Reservoir Distribution Plate: L: 500mm x W: 400mm x H: 100mm. 4kg.
Phanteks Elite Mid Distribution Plate: L: 600mm x W: 400mm x H: 100mm. 4kg.

Installation:
This distribution plate set includes a horizontal distribution plate which installs on to the mid plate of the Phanteks Enthoo Elite below the motherboard and a vertical distribution plate which mounts to the reservoir mounting area next to the motherboard. Both distribution plates mount to existing holes on the case. The vertical distribution plate uses the mounting rails on the case and can be moved closer or further from the motherboard.
