2nd PSU Starter Node

In stock

Order processing time 1-2 days.

  • Custom-designed Singularity Computers component
  • Dual-layer PCB with high-quality components
  • Starts a second PSU simultaneously with the main system
  • Ideal for multi-PSU systems and water-boxes
  • Simple installation with minimal cable clutter

Manuals

US$29.00

All US Tariff Costs Covered By Singularity Computers
  • Made In Australia
  • Lifetime warranty & expert support
Fully secured - SSL CheckoutAccepted payment methods
EAN: 9362188003282 SKU: SC-PSU-N Categories: , ,

Description

Read More +Read Less − full description

A custom designed Singularity Computers component with high-quality components and a dual layer PCB. The PCB and connectors are black with white logos and labelling. The 2nd PSU Starter Node is for starting a second PSU at the same time as your main system. This is for systems with multiple PSUs or if you are running a water-box which has its own PSU. It is simple to use and keeps cable clutter to the minimum. Plug the 24pin from the second PSU into the 2nd PSU Starter Node and run a PWM cable from the motherboard of the main system to the 2nd PSU Starter Node.

Specifications

SC 2nd PSU Starter Node. Black Dual Layer PCB.
Connectors: 24pin x1. 4pin PWM x1.
Cable: Black PWM 500mm.
PCB Dimensions: L: 80mm x W: 10mm x H: 12mm.
Packaged Dimensions & Weight: L: 150mm x W: 100mm x H: 20mm. 0.1kg.

Installation:
Plug the 24pin from the second PSU into the 2nd PSU Starter Node and run a PWM cable from the motherboard of the main system to the 2nd PSU Starter Node.
