Spectre 4 Enterprise Worksation Water-cooling Case

In stock

Order processing time 1-2 days.

  • Enterprise workstation case designed for AMD Threadripper and AMD EPYC single- or dual-socket SSI motherboards
  • Supports up to 7 single-slot GPUs and dual ATX power supplies
  • Supports up to 3x 360mm radiators or a MO-RA IV 4000 with 2x 420mm radiators
  • Integrated rear-wall distribution plate for clean, streamlined water-cooling loop routing
  • Patented Singularity Computers PowerBoard eliminates the need for traditional cable management
  • PowerBoard features temperature-based RPM control, separate PWM zones, dedicated PWM pump headers, PSU jump-start functionality, pump power headers and temperature sensor inputs
  • Dual integrated D5 pump mounting locations for high performance and redundancy
  • CNC-machined black Acetal/POM distribution plate with coolant-level viewing window
  • Engineered for higher operating pressures and temperatures
  • Enhanced development and testing processes with tighter manufacturing tolerances
  • Premium materials and advanced manufacturing processes
  • Backed by Singularity Computers’ lifetime warranty

Manuals

US$2,499.00

Select GPU Cables (included)
None 8pin PCIE x3 12V2x6/PCIE 5.1

12V2x6/PCIE 5.1
Black sleeved cables which connect from the PowerBoard to the GPU.

Input your motherboard brand and model and we will provide the correct cables for it.

Optional Add-Ons

Enhance your purchase with these recommended extras

Water Cooling

D5 Pump x2 (optional) USD $208
None Yes +US$208.00

Protium D5 Pump
The Protium 3.0 D5 Pump is compatible with all products which fit a D5 pump. The D5 pump has legendary reliability and performance. We have used it in almost every system we have ever built. The pump moves 1500LPH of fluid and has a head pressure of 3.7M. It has a Molex connector for power and a PWM connector to control the RPM.

SC Fittings Package Spectre 4 Extreme (optional) USD $542.80
None Yes +US$542.80

SC Fittings Package Spectre 4 Extreme
Fittings needed with Spectre 4 Elite x2, Spectre 4 Dual Loop Side Panel or all addon distribution plates.
Included Fittings:
– 16mm Hardline Compression: x14.
– 90 Degree Rotary: x16.
– 90 Degree Dual Rotary: x7.
– 20mm Extension: x7.
– 25mm Extension: x3.
– Telescopic Fitting Large: x5.
– Telescopic Fitting Small: x4.
– Temperature Sensor Fitting: x2.
– Low Profile Drain Valve: x2.

SC Cerakote Fittings Package Spectre 4 Extreme (optional) USD $192
None Armour Black +US$192.00 Cobalt +US$192.00 Gold +US$192.00 Midnight Bronze +US$192.00 Polar Blue +US$192.00 Ruby Red +US$192.00 Shimmer Aluminum +US$192.00 Sniper Grey +US$192.00 Stormtrooper White +US$192.00

SC Cerakote Fittings Package Spectre 4 Extreme
Tough heat treated Ceramic coating available in various colours. Order processing time 1 week.

PowerBoard

FanGuardian PowerBoard Controller (optional) USD $149
None Yes +US$149.00

Fanguardian PowerBoard Controller
The FanGuardian PowerBoard Controller can be used with many of our newer PowerBoards. It is a 3.5” touch screen in a hard case. It controls ARGB lighting colors and has different effects and functions. It monitors RPMs, temperatures and voltages. It has an inbuilt Ambient Temperature Monitor. A low RPM warning can be set on all PWM channels. It has updateable Software/Firmware and we will continue adding features.

PowerBoard PSU Cable Kit (optional) USD $79
None Yes +US$79.00

PowerBoard PSU Cable Kit
Stock PSU cables will work with the PowerBoard on the input side, but this is a short, clean, black sleeved cable set which can be used instead. This is a custom cable set which is specifically designed for your PSU.
Black sleeved cables which connect from the PSU to the PowerBoard.
We are unable to build cables for Thermaltake PSUs.

Shift Motherboard 24pin 90 Degree Adaptor (optional) USD $24.50
None Yes +US$24.50

Shift Motherboard 24pin 90 Degree Adaptor
The Shift 24pin 90 Degree Adaptor is for motherboards with 90 degree 24pin connections so that a clean connection can be made with the 24pin cable from the PowerBoard to the motherboard. Custom designed PCB with high quality components and a dual layer PCB. The PCB and connectors are black, and the PCBs have white logos and labelling.

Mounting

Second PSU Mount (optional) USD $99
None Yes +US$99.00

Spectre-4-Dual-PSU-Mount
Mounts a second PSU inside of the front panel.

Finish & personalisation

PSU Side Shroud PCB Customization
We can laser etch your name, build name or any text less than 30 characters onto the PSU Shroud. Enter text in the box below.

Additional options

Rear Panel (optional) USD $199
None Yes +US$199.00

Spectre 4 Rear Panel
The Spectre 4 Enterprise & Quantum Rear Panel is an addon for the Spectre 4 Enterprise and Quantum Water-cooling Cases. These cases come with a rear radiator mount designed to fit a MORA IV 400 or 3x 360mm radiators. This addon is to replace the rear radiator mount to improve the aesthetics, if you do not want to install radiators. It is built from CNC machined acrylic and mounts onto the rear of the main case distribution plate, it comes included with ARGB lighting.

  • 1x Spectre 4 Enterprise Worksation Water-cooling Case
    US$2,499.00

Subtotal excludes shipping & tax

Free shipping on orders over US$2,000
  • Made In Australia
  • Lifetime warranty & expert support
Fully secured - SSL CheckoutAccepted payment methods
EAN: 9362188003718 SKU: SC-ENT-WS Categories: , ,

Description

Read More +Read Less − full description

Spectre 4 Enterprise Workstation Water-cooling Case is designed for workstations using AMD Threadripper or AMD Epyc Single or Dual Socket SSI motherboards. It can fit up to x7 single slot GPUs and dual ATX PSUs. It fits up to 3x 360mm radiators or a MORA IV 4000 and x2 420mm radiators. It has Singularity Computers water-cooling integration via a distribution plate which makes up the rear wall of the case. It has the patented Singularity Computers PowerBoard which removes the need for cable management while integrating many features.The PowerBoard comes with a vast range of features including temperature-based RPM control, separate PWM zones, dedicated PWM pump headers, PSU jump start for running the pumps, pump power headers, temperature sensor inputs and more. Spectre 4 Enterprise has x2 integrated D5 pump mounting locations for high performance and redundancy. The distribution plate is built from CNC machined black Acetal/POM and there is a viewing window for the coolant level.

Singularity Computers Enterprise:
Singularity Computers Enterprise is a product line designed for professional and enterprise use. The products are engineered to handle higher pressures and temperatures. All Singularity Computers products have a lifetime warranty but our Enterprise line goes through a far more stringent development and testing process. They have tighter tolerances and higher end manufacturing processes and materials are used.





Specifications

Water-cooling Integration:
Reservoir, Pump Top, Pump Cover, Fill Port, Drain Port, Parts of water-cooling loop.
Ports: x8 G1/4” BSPP. 1x Fill Port. 2x Drain Ports.
Pumps: (Not included): Compatible with all D5 pumps.
Electronics Integration:
Connectors: 24pin x1. PCIE 8pin x4. 12VHPWR x2. 8pin EPS x4. PCIE 6pin Supplementary x1. (Equal inputs and outputs must be used).
Hubs: PWM Fan Hubs x2 each with x1 input and x3 outputs. With coolant temperature-based RPM control or motherboard control Pump inputs and outputs x2. Each fan hub and pump output have coolant temperature-based RPM control or can be switched to motherboard RPM control. The built-in RPM control on the PowerBoard is independent of the motherboard and no software is needed.
Dedicated PWM header for 140mm fan which can be mounted behind the motherboard (controlled by PWM fan hub 1).
PWM Control: 4x potentiometers to set the minimum PWM speed.
ARGB: x13 with one input.
Temperature sensor inputs: x2 for up to two loops. Compatible any water-cooling brand plug temperature sensor or inline sensor if it is a 10K NTC thermistor.
LEDs: x28 Integrated ARGB 90-degree LEDs and x28 UV 90-degree LEDs around the external perimeter of the PowerBoard. There are dip switches to turn the ARGB and UV LEDs on or off separately and stand-by UV lighting can be disabled.
Power and Reset Buttons.
PowerBoard direct mount 1 x 2.5” and 1 x 2.5”/3.5” SATA 3.0 6Gb/s accessible from the back of the distribution plate.
4pin ATX header to power up to two pumps with custom cables from the PowerBoard.
12pin header for future controller addon.
PSU jump-start switch to run the pump/s without booting so that you can run only the pump for filling the loop.
Cables: PowerBoard Linking Cables Standard Set: 24pin x1. 8pin EPS x2. 8pin PCIE x3 or 12VHPWR (select above). 18AWG Black Headshrinkless Sleeve.
PWM Female to Female 50cm Black Sleeved x1.
ARGB Female to Female 50cm Black Sleeved x1.
Touch Power Button Cables: Power, Reset, Black 20cm. PowerBoard to Horten Touch Module 60cm Black.
LED Strips: ARGB 5V 50cm x3 (pre-installed).
Motherboard Form Factor: SSI-EEB, SSI-CEB, XL-ATX (Up to: 290mm Wide & 350mm High).
E-ATX, ATX, M-ATX, Mini-DTX, Mini-ITX.
Expansion Slots: x8.
Case Form Factor: Full Tower Water-cooling Case.
Storage: x4 x2.5” x2 are on top of the PSU shroud and cannot be used when the GPUs are vertically mounted. x2 are on the rear side of the PowerBoard, x1 is optional 2.5” or 3.5”.
Radiators: 420mm/360mm X2 with 100mm of thickness for radiators and fans.
Maximum GPU Length: 445mm with 60mm front radiator and 25mm fans.
Maximum GPU Height: 170mm in standard orientation, unlimited in vertical orientation.
Maximum CPU Cooler Height: 170mm.
Maximum PSU Length: 240mm with a large amount of space for cables.
Front Panel I/O: No Front I/O.
Power Button: Touch Activated
Vertical GPU Mount: Vertical GPU mounting brackets with PCIE 4.0 Riser Cable. 2nd Vertical GPU Mount is available separately.
Materials: 6061 Aluminum Anodized. Cast Acrylic. Stainless Steel. PCB.
Manufacturing Process: CNC Mill, CNC Lathe, CNC Router, PCB.
Assembly: Distribution Plate Assembled by Hand. The case is flat packed, and the metal components need to be assembled by the customer.
Testing/Validation: All Distribution Plates are factory pressure tested and precise fastener tension is applied.
Case Dimensions: L: 550mm x W: 250mm x H: 615mm.
Case Weight: 12kg.
Packaged Dimensions: L: 640mm x W: 620mm x H: 110mm (Case is flat packed).
Packaged Weight: 15kg.

Spectre 4 Versions
Spectre Spectre 4 Aeternus Spectre 4 Aeternus Dark Spectre 4 Aeternus Valhalla Spectre 4 Carbon Spectre 4 Enterprise Spectre 4 Quantum Spectre 4-M Spectre 4-M Dark Spectre 4-M Valhalla
Distribution Plates x2 x1 x2 x2 x2 x1 x2 x1 x2 x2
Distribution Plate Layers x2 x4 x4 x4 x4 x2 x2 x2 x3 x3
PowerBoard Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
Motherboard Form Factor Up to E-ATX Up to E-ATX Up to E-ATX Up to E-ATX Up to E-ATX Up to E-ATX, SSI-EEB, SSI-CEB Up to E-ATX, SSI-EEB, SSI-CEB Up to ATX Up to ATX Up to ATX
IO Slots 8 8 8 8 8 8 8 7 7 7
Radiators 2x 360mm/420mm 2x 360mm/420mm 2x 360/420mm 2x 360/420mm 2x 360/420mm 2x 360mm/420mm + 3x 360mm or MO-RA3 2x 360mm/420mm + 3x 360mm or MO-RA3 2x 360mm 2x 360mm 2x 360mm
Radiator Thickness 60mm 60mm 60mm 60mm 60mm 60mm 60mm 45mm 45mm 45mm
Pump/s D5 D5 D5 D5 D5  2x D5  2x D5 D5 D5 D5
Reservoir Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
Case Dimensions 550mm x 250mm x 615mm 610mm x 245mm x 560mm 610mm x 245mm x 600mm 610mm x 245mm x 600mm 610mm x 245mm x 600mm 610mm x 245mm x 560mm 610mm x 245mm x 560mm 486mm x 245mm x 528mm 506mm x 245mm x 528mm 506mm x 245mm x 528mm
1920×480 60Hz Screen No No Yes Yes Yes Yes Yes No Yes Yes
Limited Edition Yes Yes Yes Yes Yes No Yes No No No
Individually Numbered Yes Yes Yes Yes Yes No Yes No Yes Yes
Rear CPU Socket Fan Yes Yes Yes Yes Yes No No Yes Yes Yes
Dust Filters No Yes Yes Yes Yes Yes Yes No No No
Multi Zone PWM Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
Dedicated Pump PWM Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
Dedicated Pump Power Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
Temperature Based RPM Control Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
RPM Curve Adjustment Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
PSU Jump Start Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
PSUs x1 x1 x1 x1 x1 x1 (2nd can be added with optional addon) x1 (2nd can be added with optional addon) x1 x1 x1
Water-cooling Loops x1 (2nd can be added with Dual Loop Side Panel) x1 (2nd can be added with Dual Loop Side Panel) x1 (2nd can be added with Dual Loop Side Panel) x1 (2nd can be added with Dual Loop Side Panel) x1 (2nd can be added with Dual Loop Side Panel) x1 (2nd can be added with Dual Loop Side Panel) x1 (2nd can be added with Dual Loop Side Panel) x1 (2nd can be added with Dual Loop Side Panel) x1 (2nd can be added with Dual Loop Side Panel) x1 (2nd can be added with Dual Loop Side Panel)
Color Black with Silver Flake & Clear Black & Clear Black & Grey Tinted White & Clear Carbon Fiber, Black & Clear Black & Clear Black, Clear & Silver or Gold Black & Clear Black & Grey Tinted White & Clear
Drives x3 x2.5” and x1 2.5”/3.5” -2 2.5” if GPU/s vertically mounted x3 x2.5” and x1 2.5”/3.5” -2 2.5” if GPU/s vertically mounted x3 x2.5” and x1 2.5”/3.5” -2 2.5” if GPU/s vertically mounted x3 x2.5” and x1 2.5”/3.5” -2 2.5” if GPU/s vertically mounted x3 x2.5” and x1 2.5”/3.5” -2 2.5” if GPU/s vertically mounted x2 2.5” if GPU/s not vertically mounted x2 2.5” if GPU/s not vertically mounted x2 x2.5” x2 x2.5” x2 x2.5”
Personalised etched name and serial number No No Yes Yes Yes No Yes No No No
Carbon Fiber No No No No Yes No No No No No
PCB Covers with integrated ARGB Yes Yes Yes Yes Yes No Yes No Yes No
